Yalex single braid rope
Yale Yalex - a single-braid 12-strand rope
Yalex is a single-braid 12-strand rope constructed of premium over finish polyester fiber. Yalex’s two-end-per-carrier structure creates a larger void in the middle of the rope, which makes it easier to splice and makes used-rope splicing much easier to perform.
- Easy to splice
- Maxijacket urethane coating reduces snagging
- Option to color code for application or load rating
- Yarn treated with marine grade finish prior to twisting
- 2-ply construction helps retain shape
Yalex is always coated with Yale’s Maxijacket urethane coating, which reduces the new rope’s tendency to snag, greatly enhances abrasion resistance, and is a great way to color code ropes for application or load rating.
| YALEX | |||||
| Diameter | Avg. Spliced Break Strength* |
Min. Spliced |
Max. Work Load 5:1 ** |
Weight | |
| 5/8" | 16mm | 9,485kG | 8,537kg | 1,897kg | 17.3kg / 100m |
| 3/4" | 19mm | 12,255kg | 11,030kg | 2,451kg | 23.1kg / 100m |
| 7/8 | 22mm | 19,110kg | 17,199kg | 3,822kg | 34.2kg / 100m |
* Knots and abrupt bends significantly reduce the strength of all ropes and lower the maximum working load.
** Working load is based on static or moderately dynamic lifting/pulling operations. Instantaneous changes in load, up or down, in excess of 10% of the rope’s rated working load constitute hazardous shock load and would void the normal working-load recommendation. Consult Yale Cordage for guidelines for working loads and the safe use of rope.
Specific Gravity: 1.38
Dielectric Strength: The maximum allowable leakage for clean, dry Yalex is 100 micro-amperes when tested at 100kV per Yale Method 712-1701 Rev 1 “Routine Production Test.” Absorbed and entrained moisture or impurities will increase rope's conductivity dramatically.
